500-4C is a 4 mm C-Type / bevel soldering tip from the 500 Series lead-free soldering tip range. Its angled working face provides good heat transfer and solder flow, making it suitable for PCB pads, component leads, terminals, connectors, and medium-to-large solder joints. A 4.0 mm tip width, 45° angle, 19.5 mm working section, and 21 mm tip section length.
| Parameter | Specification |
|---|---|
| Brand | Generic |
| Model / Part No. | 500-4C |
| Product Type | Soldering Tip / Bit |
| Tip Series | 500 |
| Tip Shape | C-Shape |
| Tip Width | 4.0 mm |
| Working Section Length | Approx. 19.5 mm |
| Tip Section Length | Approx. 21 mm |
| Series Type | Lead-Free Soldering Tip |
| Compatible Stations | BAKON BK3300L, BK3300A & BK3600 |
| Other Compatibility | Quick 205 & Compatible 500-Series Stations |
| Installation Type | Replaceable Soldering Tip |
| Primary Function | General & High-Heat Soldering |
| Suitable For | Medium-to-Large Solder Joints |
| Typical Usage | PCB Pads, Component Leads, Terminals & Connectors |
| Application Area | Electronics Assembly, Repair & PCB Rework |
