1200mm MCPCB Cutting Machine

The 1200mm MCPCB Cutting Machine is an industrial PCB depaneling solution designed for accurate cutting and separation of Metal Core Printed Circuit Boards (MCPCBs), particularly aluminium-based PCBs.

With a maximum cutting length of 1200 mm, the machine is suitable for processing long-format MCPCB panels commonly used in LED lighting, power electronics and electronics manufacturing.

The machine uses a controlled cutting mechanism with circular cutter / linear blade configurations, depending on the machine setup. Adjustable cutting speed allows the cutting process to be optimized according to board material and thickness.

Its controlled separation process is intended to minimize mechanical stress, vibration and board deformation during depaneling, helping maintain the structural integrity of the MCPCB and mounted components.

The machine is particularly suitable for long LED aluminium PCBs, including boards used for tube lights, strip lights, panel lights and other LED lighting assemblies.

Technical Specifications

Parameter	Specification
Product Name	1200mm MCPCB Cutting Machine
Product Type	MCPCB Cutting / Depaneling Machine
Maximum Cutting Length	1200 mm
PCB Type	MCPCB / Aluminium PCB
Cutting Method	Circular Cutter / Linear Blade
PCB Thickness Range	0.6 mm – 3.5 mm
Cutting Speed	Adjustable
Operation Mode	Manual / Semi-Automatic
Blade Material	High-Speed Steel / Tungsten Carbide
Machine Structure	Heavy-Duty Industrial Frame
Cutting Accuracy	High-Precision Cutting
Power Supply	220V / 50Hz
Control System	Mechanical / Electronic
Noise Level	Low-Noise Operation
Safety Features	Safety Guards & Emergency Stop
Maintenance	Low-Maintenance Design
Primary Application	Long-Format MCPCB Cutting & Depaneling

Key Features

Maximum 1200 mm cutting length
Designed for MCPCB / aluminium PCB
Suitable for long-format PCB panels
Adjustable cutting speed
Controlled precision cutting
Circular cutter / linear blade configuration
Supports 0.6–3.5 mm PCB thickness
Heavy-duty industrial construction
Helps reduce mechanical cutting stress
Helps minimize board cracking and deformation
Produces clean and consistent separation
Suitable for high-volume production
Safety guard provision
Emergency-stop provision
220V / 50Hz operation

Applications

MCPCB Depaneling – Separation of metal-core PCB panels into individual boards.
Aluminium PCB Cutting – Precision cutting of aluminium-based printed circuit boards.
Long LED PCB Cutting – Suitable for long-format LED MCPCB panels up to 1200 mm.
LED Tube Light PCB Production – Used for cutting long aluminium PCBs used in tube-light manufacturing.
LED Strip & Panel Lights – Suitable for MCPCB processing for LED strip and panel-light applications.
LED Lighting Manufacturing – Supports high-volume production of aluminium-core LED boards.
Power Electronics – Suitable for metal-core boards used in thermal-management-intensive electronic assemblies.
Automotive Electronics – Used for compatible MCPCB depaneling applications.
SMT Production – Supports PCB separation as part of electronics manufacturing workflows.
Industrial Electronics – Suitable for precision separation of compatible metal-core circuit boards.
High-Volume PCB Manufacturing – Adjustable cutting and long-board capability support repetitive production operations.
